Circuit :DPDT 2P2T Current Rating :100mA Voltage Rating :30VDC Dielectric withstanding voltage :250VAC ftor 1 minute Contact Resistance :100mΩ Max .(intial) Insulation Resistance :100MΩ Min. Operating Force :150±100(MOM) Total Travel :1.6±0.4mm Opearating life :50,000 Cycles Min Soldear Specifications :260°C for 5 Seconds Function :Momentary or self-lock Openrating Temperature :-20°C~+ 70°C
